New Product Launch!
XINTAI P3.91 Holographic LED Screen Separate LED & Driver —an excellent-value solution for indoor glass installations.
✓ 2,000 / 4,000 nits optional
✓ Up to 50% energy saving
✓ Low current and low heat
✓ Clear transparency
Lower Power. Lower Heat. Better Value.
P3.91 Holographic LED Screen with Separate LED & Driver is a cost-effective transparent LED solution for indoor retail stores, showrooms, exhibitions and glass window displays. Featuring SMD1516 LEDs, SM16719 driver ICs, 2,000 nits standard brightness and a 7,680Hz refresh rate, it delivers stable performance with lower power consumption and lower operating heat.
P3.91 Holographic LED Screen SPECIFICATIONS | ||
| No. | Parameter | P3.91 (Separate LED & Driver) |
| 1 | Pixel Pitch (H × V) | 3.91 × 3.91 mm |
| 2 | Pixel Density | 65,536 pixels/m² |
| 3 | Display Layer Thickness | 2 mm |
| 4 | LED Package / Driver Structure | SMD1516 / Separate |
| 5 | PCB Layers | 4 Layers |
| 6 | Standard Unit Size | 1500 × 250 mm / Customizable |
| 7 | Max. Power Consumption (per standard unit) | 130 W @ 2200 cd/m² |
| 8 | Weight (per standard unit) | 0.90 kg excl. power supply 1.32 kg incl. power supply |
| 9 | Transparency | >68% |
| 10 | IP Rating | IP30 |
| 11 | Expected LED Lifetime | >100,000 hours |
| 12 | Input Voltage / Frequency | AC 100–240 V, 50/60 Hz |
| 13 | White-Balance Brightness | 1200–2200 cd/m², adjustable |
| 14 | Recommended Viewing Distance | 4-80 m |
| 15 | Viewing Angle (H / V) | 160° / 140° |
| 16 | Grayscale | ≥16 bit |
| 17 | Scan Mode | 1/16 scan |
| 18 | Brightness Degradation | <0.05% within 2 years |
| 19 | Refresh Rate | 7680 Hz |
| 20 | Frame Rate | >60 Hz |
| 21 | Mean Time Between Failures (MTBF) | >10,000 hours |
| 22 | Defective LED Rate | <0.01%, randomly distributed |
| 23 | Control System | Colorlight / NovaStar; synchronous or asynchronous |
| 24 | Operating / Storage Conditions | Operating: -20 to +55°C, 20–80% RH, non-condensing Storage: -30 to +65°C, 10–85% RH, non-condensing |
| 25 | Installation | Glass mounting, hanging or fixed installation; supports project-specific cutting and bending. |
| 26 | Application Environment | Indoor |
1.Is this product suitable for outdoor installation?
No. The P3.91 Separate LED & Driver Holographic Screen is rated IP30 and designed for indoor applications.
2. What is the standard brightness?
The standard brightness is 2,000 nits. A customized 4,000-nit version is available for projects with stronger ambient lighting.
3. Can it be installed on glass?
Yes. The LED-emitting surface can be mounted against the glass. However, the rear surface cannot be directly attached to the glass because independent driver components are arranged on the back.
4. Can the screen be cut to a custom size?
Yes. The product supports project-specific cutting and customized dimensions, subject to circuit layout and engineering confirmation.
5. Can it be used as a freestanding LED poster?
Yes. It can be integrated into a freestanding poster structure for retail, exhibition and promotional applications.
6. Is it suitable for photography and video recording?
Yes. Its 7,680 Hz refresh rate helps deliver smooth, camera-friendly visual performance.
7. Which control systems are supported?
The screen supports Colorlight and NovaStar control systems, with synchronous or asynchronous control options.
8. How do I choose between 2,000 and 4,000 nits?
The 2,000-nit version is recommended for standard indoor environments. The customized 4,000-nit version is suitable for brighter locations. We recommend providing installation photos and ambient-light information before quotation.
Request a Customized Solution
Every glass installation has different dimensions, lighting conditions and viewing requirements.
Please send us the following information:
XINTAI will recommend the appropriate brightness, unit layout, control system and installation solution for your project.
